Dual Function Top Hung & Pivot Windows - FAKRO

Top hung and pivot window preSelect

  • Top hung and pivot window preSelectA new generation of top hung and pivot windows with two separate opening functions of sash: top hung and pivot.
  • Separate opening functions provide sash stability and increase safety.
  • The outward opening function enables the sash to be opened in any poisition from 0 to 35 degrees enabling easy approach to the edge of the open windows, which increases the usable area and provides unlimited view to the outside.
  • The pivot function enables the sash to be rotated through 180 ° and is used when cleaning the outer pane or operating an awning blind. Innovative hardware system guarantees the use of only one way of opening and complete stability of the sash in outward as well as in pivot opening function.
  • Opening method can be switched using the preSelect sliding switch positioned in the middle of the frame accessible when the window is open.
  • Comfort of operation when using the handle located at the bottom of the sash. Elegant handle is equipped with a two step microopening facilty.
  • Easy cleaning of the outer pane and setting the awning blind with the use of blocking sash bolt when rotated through 180 degrees.
  • Available as standard with energy-saving glazing U3.
  • Increased resistance to burglary - TopSafe system.

Dual Function Top Hung & Pivot Windows - FAKRO thermoPro technology as standard

System topSafeTopsafe® system of burglary protection as standard





  • FPP-V preSelect


    • Air inlet V40Pautomatic air inlet V40P
    • Highest quality pine woodhighest quality pine wood, glued in layers, vacuum impregnated
    • Wood painted twice with ecological acrylic lacquerwood painted twice with ecological acrylic lacquer in natural colour
    • 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 32 dB acoustic insulation Rw 4H-16-4T glazing unit argon inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow twice varnishing four seals + multi-point opening Elegant handle
    • 0.97 W/m²K window U-value 0.5 W/m²K glazing U-value 33 dB acoustic insulation Rw 4HT-10-4H-10-4HT glazing unit krypton inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow twice varnishing four seals + multi-point opening Elegant handle
  • FPU-V preSelect


    • Air inlet V40Pautomatic air inlet V40P
    • Highest quality pine woodhighest quality pine wood, glued in layers, vacuum impregnated
    • Wood painted three times with ecological acrylic lacquerwith three coats of polyurethane varnish ideal for creating a durable and smooth finish in white on the frame surface
    • Designed for kitchens and bathroomsdesigned for rooms with periodically elevated humidity levels (kitchens, bathrooms)
    FPU-V U3 preSelect
    • 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 32 dB acoustic insulation Rw 4H-16-4T glazing unit argon inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow triple varnishing four seals + multi-point opening Elegant handle
  • PPP-V preSelect


    • Air inlet V35efficient air inlet V35
    • Multi chamber white PVC profilemulti chamber white PVC profile with reinforced steel core
    • Multi chamber oak or pine PVC profileavailable in golden oak or pine veneer
    • Window is durable and resistant to corrosionthe material does not absorb moisture, the window is durable and resistant to corrosion
    • Designed for kitchens and bathroomsdesigned for rooms where elevated humidity level stays for long time (bathrooms, laundry rooms)
    • 1.1 W/m²K window U-value 0.5 W/m²K glazing U-value 34 dB acoustic insulation Rw 4HT-10-4H-10-4HT glazing unit krypton inert gas filled panes + external glass toughened V35 air inlet type up to 41 m³/h air inlet air flow - varnishing four seals + multi-point opening Elegant white handle
    • 1.1 W/m²K window U-value 1.0 W/m²K glazing U-value 31 dB acoustic insulation Rw 4H-16-4T glazing unit argon inert gas filled panes + external glass toughened V35 air inlet type up to 41 m³/h air inlet air flow - varnishing four seals + multi-point opening Elegant white handle
