Type G flat roof windows – with flat glass section - FAKRO

Type G flat roof windows – with flat glass section

A new line of D_G windows combines illumination of rooms under the flat roof and innovative look at design. These products put together innovative appearance of type F windows which were given Red Dot Design Award 2016 and design of type C windows. D_G flat roof windows are technically advanced and therefore feature the best thermal insulation performance on the market.

Glazing unit

Windows are offered with P2 glazing unit which comes with a Class P2A inner laminated pane to secure safety of use and protect against shards of glass in case of damage. Optionally, there is available laminated P4 anti-burglary glazing unit featuring P4A class.

Accessories

The window structure enables installation of internal accessories.

Installation angle

With patent-pending rainwater drainage system from the window surface, its installation is possible even in the roof pitch of 2°.

Available sizes

Windows come in 9 standard sizes from 60x60cm to 120x120cm and 100x150cm. On request, windows can be manufactured in non-standard sizes in the range of 60x60 – 120x120cm. This enables existing skylights which do meet current thermal insulation requirements to be replaced with ease.
  • DEG P2


    electrically opened with wireless Z-Wave system
    • 0,92 W/m²K window U-value 1,1 W/m²K glazing U-value 4H – Tg14Ar- 33.2T + 4H; 4H – Tg14Ar – 33.2T + 6H glazing unit argon inert gas filled panes + internal glass laminated, anti-burglary glass class P2A class 4 Air Leakage [cfm/ft2]




  • DMG P2


    manually opened by means of included 2.2m long control rod
    • 0,92 W/m²K window U-value 1,1 W/m²K glazing U-value 4H – Tg14Ar- 33.2T + 4H; 4H – Tg14Ar – 33.2T + 6H glazing unit argon inert gas filled panes + internal glass laminated, anti-burglary glass class P2A class 4 Air Leakage [cfm/ft2]




  • DXG P2


    electrically opened with wireless Z-Wave system
    • 0,92 W/m²K window U-value 1,1 W/m²K glazing U-value 4H – Tg14Ar- 33.2T + 4H; 4H – Tg14Ar – 33.2T + 6H glazing unit argon inert gas filled panes + internal glass laminated, anti-burglary glass class P2A class 4 Air Leakage [cfm/ft2]
